KJM432-750 |
 |
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
2 |
750 |
3600 |
11.2 |
|
| |
| |
|
KJM432-750 |
 |
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
2 |
750 |
3600 |
13.6 |
|
| |
| |
|
KJM432-1500 |
|
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
2 |
1500 |
3600 |
18.7 |
|
| |
| |
|
KJM432-2200 |
|
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
4 |
2200 |
3600 |
21.0 |
|
| |
| |
|
KJM432-3700 |
|
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
2 |
3700 |
3600 |
31 |
|
| |
| |
|
KJM434-200 |
|
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
4 |
200 |
1800 |
7.6 |
|
| |
| |
|
KJM434-400 |
|
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
4 |
400 |
1800 |
9.1 |
|
| |
| |
|
KJM434-400 |
|
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
4 |
400 |
1800 |
10.5 |
|
| |
| |
|
KJM434-750 |
|
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
4 |
750 |
1800 |
13.5 |
|
| |
| |
|
KJM434-1500 |
|
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
4 |
1500 |
1800 |
19.6 |
|
| |
| |
|
KJM434-2200 |
|
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
4 |
2200 |
1800 |
28.8 |
|
| |
| |
|
KJM434-3700 |
|
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
4 |
3700 |
1800 |
33.8 |
|
| |
| |
|
KJM436-400 |
|
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
6 |
400 |
1200 |
13.5 |
|
| |
| |
|
KJM436-750 |
|
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
6 |
750 |
1200 |
19.6 |
|
| |
| |
|
KJM436-1500 |
|
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
6 |
1500 |
1200 |
28.8 |
|
| |
| |
|
KJM436-2200 |
|
|
|
| |
|
Phase |
Rated voltage
(V) |
Frequency (Hz) |
Number of poles
(P) |
Rated power
(W) |
Revolution per minute
(r.p.m) |
Weight
(kg) |
|
3-phase |
220/380 |
60/50 |
6 |
2200 |
1200 |
33.8 |
|
